RS PRO Centrifugal Fan, 24 V dc, 30cfm, DC Operation, 120 x 120 x 31mm

RS PRO Centrifugal Fan, 120 x 120 x 31 mm, 30 CFM, 24 V DC

This centrifugal fan or blower from RS PRO recirculates and propels air in air conditioners and air conveyors. You'll commonly find it used in HVAC (heating, ventilation and air conditioning) systems in home and office environments.


The frame and impeller are made of polybutylene terephthalate (PBT), which won't ignite or act as a source of fuel in the event of a fire. As the fan is chemical and stain-resistant, it's easy to clean, saving you time during maintenance. The blower is also easy to install as it comes with pre-drilled holes. It complies with the RoHS (Restriction of Hazardous Substances) requirements, meaning it contains only minimal amounts of any harmful materials.

Features and Benefits

• DC operation


• Airflow of 30 CFM (cubic feet per minute)


• Ball-bearing type


• Blower type


• Brushless commutation type


• Dimensions of 120 x 120 x 31 mm


• Forward direction of curve


• Fan speed of 3000 rpm (rotations per minute)


• Maximum current of 370 mA


• Mounting hole diameter of 3.2 mm


• Noise level of 49 dB(A)


• Static pressure of 0.49 in/H2O


• Supply voltage of 24 V DC


• Lead wire termination type
