RS PRO Universal Joint, Single, Plain, Bore 10mm, 48mm Length, Шарнирная муфта

RS PRO Universal Joint, Single, Plain, Bore 10 mm, 48 mm Length

Do you need to connect rotating machinery at sharp operating angles? These universal joints from RS PRO are designed for connecting vehicle prop shafts as well as conveyors and line shafts to a prime mover – in any type of machinery, really, where there is a misalignment greater than 5 degrees.

Made from solid steel, these plain bearings have a bored hub with an outer diameter of 22 mm. They're suitable for applications with a maximum operating angle of 45° and a maximum speed of 1000 rpm. Note that to ensure smooth operation and the longevity of the joints, we recommend regular lubrication and a protective gaiter when using in vehicles or with machinery.

As part of the tried and tested RS PRO range, this product has undergone stringent quality controls to ensure a safe and reliable product.

Features and Benefits

• Universal joint
• Plain single-joint type
• Made from steel
• Bored hub type
• Maximum speed of 1000 rpm
• Hub outer diameter of 22 mm
• Bore size of 10 mm
• Overall length of 48 mm
• Peak torque of 600 Nm
• Maximum working angle of 45°
• Conforms to Electrostatic Control Standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007
• RoHS (Restriction of Hazardous Substances) compliant
