E3645A, Keysight Technologies Bench Power Supply, , 80W, 1 Output , , 0 → 35 V, 0 → 60 V, 1.3 A, 2.2 A With RS, Блок питания

Programmable DC Power Supplies

The 10 Keysight programmable DC power supplies on offer are:
E3640A ( 667-7362 );
• E3641A ( 667-7366 );
• E3642A ( 667-7375 );
• E3643A ( 667-7378 );
• E3644A ( 667-7372 );
• E3645A ( 667-7381 );
• E3646A ( 667-7384 );
• E3647A ( 667-7388 );
• E3648A ( 667-7397 );
• E3649A ( 667-7390 ).

With output power of 30W to 100W, depending on choice of model, these programmable DC power supplies provide great performance at a great price. All models deliver clean power, excellent regulation and fast transient response, with built-in GPIB and RS-232 interfaces.

They are designed to meet the needs of R&D design verification, production testing, QA verifications and other demanding applications.

• Single and dual outputs
• Dual range output
• 30 W to 100 W output power
• Front and rear output terminals
• Over-voltage protection
• Remote Sensing connections on the rear
• GPIB and RS-232 interfaces
• Save and recall functions for up to 5 values

Keysight Technologies Power Supply

The Keysight technologies 80W, 1-channel programmable DC power supply is portable equipment has an output voltage rating ranging between 0V to 60V and an output current rating is 1.1A and 2.2A. It provides excellent performance at a great price. The power supply is a bench mount.

Features and Benefits

Accuracy is 0.5%+0.5V
Single outputs
Dual range output
Front and rear output terminals
Over-voltage protection
Remote sensing connections on the rear
GPIB and RS-232 interfaces
Save and recall functions for up to 5 values

Applications

Industrial
Medical equipment
Electronic equipment

Certifications

UL3111-1 approved
CSA 22.2 No. 1010.1 certified
IEC 1010-1
IEC 320
EMC directive 89/336/EEC (Group 1, Class A)
