1792261, Phoenix Contact PLA 5/ 6-7.5-ZF Series PCB Terminal Block, 6-Contact, 7.5mm Pitch, Through Hole Mount, 1-Row, Spring

Phoenix Contact COMBICON PLA 7.5 mm PCB Terminal Blocks

The 7.5 mm pitch PLA series of 30° Angled, PCB mounted, Terminal Blocks from Phoenix Contact feature a push-lock spring type connection with low actuation force lever operation.
The 7.5 mm PLA PCB Terminal Block can accept solid or stranded wire from 0.2 mm² to 6 mm² (24-10 AWG).
The rated current / cross section for the 7.5 mm PLA PCB Terminal Block is 41 A/6 mm².
The material Inflammability class is UL 94 V0 for the 7.5 mm PLA PCB Terminal Block.
The PCB requires a 2 mm diameter hole for the Zig-Zag pinning pattern of the 7.5 mm PLA Terminal Block.

Phoenix Contact COMBICON 7.5mm Pitch PCB Terminal Blocks

PCB Terminal Block - PLA 5/ 6-7,5-ZF - 1792261 - Datasheet
