2903294, Phoenix Contact RIF-3-RPT-LDP-24DC/3X21 Series Interface Relay, DIN Rail Mount, 24V dc Coil, 3PDT, 3-Pole, Реле

RIF3 Power Relay Module

Professional range of power relays that come with a base, suppressor and retaining bracket that benefits from a universal plug in design.

Easy wiring due to push in connection technology
Easy handling and extension of range
Plug in display/suppressor module
AC and DC versions
2 and 3 contact options
Yellow LED indicator
Varistor or damping diode protective circuit

Phoenix Contact Non-Latching Relay Module, 3PDT - RIF-3-RPT-LDP-24DC/3X21- 2903294

With this relay from Phoenix Contact, you can control six outputs on three circuits – all from just one signal. It functions not only as an electromechanical on/off switch but also as a way of changing from one contact to another on a circuit. As a 3PDT (three poles, double throw) relay, each pole switches between two contacts when powered – one normally closed and one normally open. Non-latching means that the contacts return to their original positions when power is switched off.
You can find these relays in a variety of applications, including control panels, energy management systems and lighting controls. They can power multiple devices at the same time or be used for backup modes. This unit features a 24 V DC coil and a 250 V AC/DC maximum switching voltage. Pre-assembled parts and a plug-in terminal type make for easy installation.

• Coil power of 80 mW
• Coil resistance of 430 Ω
• Damping diode to reduce voltage spikes
• Silver alloy contact material for durability
• DIN rail mounting type
• Switching current of 2 A
• Operating temperature range of -40°C to +60°C
• Yellow LED (light-emitting diode) operating voltage display
• Mechanical service life of 20,000,000 cycles
