2903361, Phoenix Contact RIF-0-RPT-24DC/1 Series Interface Relay, DIN Rail Mount, 24V dc Coil, SPST, 1-Pole, Реле

Phoenix Contact Interface Relay, 6A Limiting Continuous Current, 1NO Contact Configuration - RIF-0-RPT-24DC/ 1 - 2903361

For dependable control of your industrial circuits, wire up this interface relay from Phoenix Contact. It uses inputs of 19.2 to 36V DC to make or break a connected electrical circuit with a voltage rating between 5 and 250V AC/DC. Galvanic isolation limits interference to ensure you get the benefit of reliable signalling efficiency.
Dimensions of 6.2 (W) x 93 (H) 66mm (D) mean this is a small bit of kit that squeezes into tight setups. With its broad operating temperature range between -40°C and +60°C, it also stands up to challenging environments. You'll know at a glance when the device is hard at work, thanks to its yellow LED status indicator. Relays like this one can be commonly found in automation networks and medical technology.

Features & Benefits

• Mechanical service life of 20 million cycles shows that it's highly reliable
• Tested up to 6kV for protection against sudden voltage surges
• Typical input current of 9mA, so it's an energy-saving component
• Supports mounting in any position to give you flexible installation options
• Base is IP20-rated, indicating it's finger-safe and protected against objects larger than 12mm
