2903370, Phoenix Contact RIF-0-RPT-24DC/21 Series Interface Relay, DIN Rail Mount, 24V dc Coil, SPDT, 1-Pole, Реле

Phoenix Contact RIF-0 Power Relay Modules

The professional range of RIFLINE complete power relays consist of a relay base with ejector and multi-layer gold contact or power contact relay.
The innovative, general purpose ice-cube relays are an excellent choice if you want to isolate, amplify or multiply signals. The universal plug-in design allows fast, easy and error free handling.

Features and Benefits

• Easy wiring due to push in connection technology
• Easy handling and extension of range
• Plug in display/suppressor module
• 1 and 2 contact options
• 5ms typical response time
• Damping diode protective circuit
• SPNO and SPDT available
• Din rail mounting
• Silver alloy contact material
• -40°C to +60°C operating temperature

Typical Applications

The Phoenix Contact RIFLINE range can offer you a solution to practically every switching application.

Phoenix Contact Non-Latching Relay Module, SPDT - RIF-0-RPT-24DC/21 - 2903370

Choose this ice-cube relay from Phoenix Contact to isolate, amplify or multiply signals in any automation system. It includes a power contact relay and a relay base with an ejector. It's an effective choice for all coupling applications.
The general-purpose unit is pluggable and can be fitted with miniature power relays or solid-state relays, making it a versatile option in industrial systems. The relay base is integrated with a freewheeling diode, so you can connect an input circuit or interference suppression circuit based on your needs. An LED (light-emitting diode) status display makes for easy operation.
Thanks to push-in wiring, this relay module is quick and easy to install and configure. Its compact design is ideal for applications where space is limited. The coil and contact are isolated, so you can be assured of system safety.

• SPDT (single pole, double throw) contact configuration
• Coil power of 170 mW
• Coil resistance of 3.388 kΩ
• Coil voltage of 24 V DC
• Silver-alloy contact material
• Switching current of 6 A
• Mechanical service life of 20,000,000 cycles
• Maximum switching power of 1.5 kVA
• Maximum switching power of 140 W
• Maximum switching voltage of 250 V AC
• Maximum switching voltage of 250 V DC
• Operating temperature range of -40°C to +60°C
• DIN rail mounting type
