UB20.241, PULS Uninterruptible Power Supply (480W), Блок питания

PULS DC UPS Control Unit

The PULS uninterruptible power supply controller (DC-UPS) unit has an output voltage of 24VDC with 20A current. It is used with a 24V power supply and batteries to bridge power failures or voltage fluctuations. This configuration can prevent frequent downtimes, long restart cycles and loss of data. A unique feature is a constant voltage in battery mode, which will not change as the batteries discharge. The buffered voltage in battery mode can be set to four different output values.

Features and Benefits

1-battery-concept each 12V battery is charged
Constant output voltage in a buffer mode
50% power reserves
Power rating is 480W
Ripple factor and noise is 120mVpp
Electronically protected against output overloads
Relay contacts for remote monitoring
Low voltage drop between input and output
Smart battery diagnostics and monitoring functions
Precise battery charging by using a temperature sensor

Applications

Industrial control
Offices
Communication and instrumentation equipment

Certifications

UL approved
CE certified

Datasheet
