Bourns 200Ω, 0603 (1608M) Thick Film SMD Resistor ±1% 35W - PWR263S-35-2000F, Резистор

35W 1% PWR263 Series ( TO263 package )

The PWR263S-35 SMD power resistor series from Bourns is rated to 35 W continuous power in a D²PAK package. The free to air power rating of the component is 2.8 W. Manufactured using thick film on alumina ceramic technology the PWR263S-35 SMD power resistor series is designed to withstand peak temperatures of 260°C during solder reflow.

PWR263S-35 SMD power resistors are available in a wide resistance range. These resistors feature pulse power handling and low inductance. PWR263S-35 Power resistors are suited to current limiting, current sensing, capacitor discharge in battery charging, AC-DC, DC-DC and DC-AC conversion circuits.

D²PAK housing
Low inductance
Resistor electrically isolated from the back plate
High power rating
Compatible with lead free solder reflow temperatures

Product Application Information

PWR263S-35 power resistors are AEC-Q200 qualified and suitable for automotive applications. Other uses include uninterruptible power supplies, telecom power supplies, welding machines and automation. Suitable applications also include aerospace, lighting and railway equipment.

Applications:-

Power supplies
Motor drives
Test and measurement
Rectifiers

Standards

AEC-Q200 qualified

Non-Inductive - Surface Mount Package

PWR263S-35 Series Power Resistor Data Sheet
