TMR 2-2412WIN, TRACOPOWER TMR 2WIN DC-DC Converter, 12V dc/ 167mA Output, 9 → 36 V dc Input, 2W, Through Hole, +90°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 1.5kV DC I/O Isolation Voltage, Non-Conductive Plastic Housing - TMR 2WIN Series - TMR 2-2412WIN

Safely transmit power signals to your PCB-connected components with this DC-DC converter from Traco Power. It balances supply voltages ranging between 9 and 36V, filtering out ripple thanks to its internal capacitor to deliver a stable 12V DC output. For additional safety, it builds an isolation barrier of up to 1.5kV between the input and output, keeping your appliance safe from the hazard of sudden voltage spikes. The unit works without flinching in operating temperatures as low as -40°C right through to +90°C, so it fits the bill for demanding conditions.

Features & Benefits

• Cools by natural convection from the environment, eliminating the need for a heat sink
• Compact dimensions of 21.8 (L) x 11.2 (W) x 9.3mm (D) make it a space-efficient choice for busy setups
• Power rating of 2W to suit light-duty applications
• Remote on/off control enables automated operation

Applications

• Gaming consoles
• Printers and scanners
• Robotics systems

How efficient is this DC-DC converter?

This unit has a high efficiency of 82%, so it's an energy-saving solution that delivers maximum productivity with minimal waste heat.

Does this component feature any other safety features?

Yes, it has integrated continuous short-circuit and overload protections to hold its ground against electrical faults.

TMR 2-2412WIN Datasheet

Industrial Power Solutions Catalogue

Selection Guide
