SRN6630X SRX-SRN6630X, ABB SRX Series 304 Stainless Steel Wall Box, IP66, 600 mm x 600 mm x 300mm, Настенный шкаф

ABB SRX Enclosures

The range of ABB stainless steel, SRX enclosures can be used indoors or outdoors and are designed to offer a high standard of protection and strength as well as a very high level of hygiene.

Features and Benefits

• Easy to mount to the wall or floor
• Door can be hinged on the left or the right side
• IP66 protection meaning that they have protection from dust and powerful water jets
• IK10 Protected against 20 Joules impact. Equivalent to impact of 5 kg mass dropped from 400 mm above impacted surface
• Made from 304 stainless steel making the enclosures resistant to oxidation and corrosion
• Chassis plate supplied
• Normal operating conditions -25 to +55°C

Typical Applications

The SRX wall mounted enclosures are ideal for using in environments such as the food, chemical and pharmaceutical industry and hospital sectors. The enclosures are also a great choice for constructing small and medium sized switchboards for automation and distribution.

Note

Enclosures do not have cable entry flanges or an inner door.

Standards

IEC EN 62208, IEC EN 60439-1, IEC 61439-1-2
Certifications UL (Underwriters Laboratories) Ex

ABB Stainless Steel Wall Box, 600 (H) x 600 (W) x 300mm (D) - SRX Series - SRN6630X SRX-SRN6630X

Use this robust wall box from ABB to house and protect electrical components in commercial and industrial areas. The steel body is durable and can withstand impact and corrosion, so you can use it in demanding and damp environments. The box comes with a distribution kit that lets you install modular devices such as circuit breakers and relays. A 19mm closing unit with a double-tongue key provides extra security and prevents unauthorised access to the cabinet.

Features & Benefits

• Dimensions of 600 (H) x 600 (W) x 300mm (D) provide ample room to store components
• Wide operating temperature range of -25°C to +55°C for use in demanding conditions
• IP66 (ingress protection) rating to withstand dust and high-pressure water jets

Applications

• Process and packaging industries
• Automation control panels
• Electrical power distribution systems

Is this wall box flameproof?

This wall box's steel body is non-combustible, which means that it won't burn if a fire occurs. It's flameproof and can help protect the components it houses from damage due to fire.

SRX Stainless Steel Enclosures Data Sheet

Control Cabinet Solutions

Brochure - SR2 and SRX

Catalogue - General Purpose Enclosures
