TEN 3-2410N, TRACOPOWER TEN 3N DC-DC Converter, 3.3V dc/ 600mA Output, 18 → 36 V dc Input, 3W, Through Hole, +85°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 750mA Output Current, 79% Efficiency - TEN 3N Series - TEN 3-2410N

Don't let high supplies overpower your low-voltage application. Grab this DC-DC converter from Traco Power to change inputs between 18 and 36V DC into a reliably steady 3.3V DC. With its integrated filter, the unit complies with EN55022 Class A requirements without adding external components, giving you the assurance it can handle heavy-duty systems. Beefed-up EMC prevents service disruptions caused by electromagnetic interference. Plus, the tough DIP-24 format gets the job done in challenging temperatures between -40°C and +80°C.

Features & Benefits

• Compact size measuring 31.8 (L) x 20.3 (W) x 10.2mm (D) takes up little space on your PCB
• 3W power rating indicates an energy-efficient unit
• Electrically safe as indicated by compliance with EN 62368-1 standards

Applications

• Consumer electronics
• Testing and measuring equipment
• Industrial control systems

How do I install this DC-DC converter?

Installing this PCB-mount component is a cinch – just punch the attached pins through the corresponding holes on your board and solder to secure it. This installation method makes it a suitable drop-in replacement for old power supplies.

Does this converter have integrated electrical protection?

Yes, it comes with protection against short circuits and overload to help prevent damage and downtime.
