1767025, Phoenix Contact 7.62mm Pitch 4 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

Phoenix Contact PCB Terminal Block, 1.3 mΩ Contact Resistance, 2.5 mm² Cross Section - GMSTB 2,5/ 4-ST-7,62 - 1767025

Want a tangle-free solution for your wiring setup? Choose this PCB terminal block from Phoenix Contact. As you can use it to connect up to four wires securely to your board, it streamlines operations. Copper alloy contacts are highly conductive and resistant to corrosion, which means minimal power loss and smooth performance. Thanks to 180° wire entry, the wires can be easily inserted and connected to the terminal block from either direction. This makes installation and maintenance simple.
This block has PA insulators that are resistant to chemicals and wear, so it's a robust option that stands the test of time. With compact dimensions of 28.48 (W) x 15 (H) x 18.2mm (L), it adds minimal bulk to your setup. A broad operating temperature between -40°C and +100°C ensures it's safe to use in harsh industrial environments to connect sensors and actuators to the control system.

Features & Benefits

• Wide pitch of 7.62mm means it's suitable for high-voltage applications
• Screw connection for secure and reliable setup
• 12A nominal current so it's widely compatible
• CSA, cULus, CB scheme, VDE and EAC certifications assure you of the unit's safety

Phoenix Contact COMBICON 7.62mm Two Part Terminal Blocks

Approvals

UL94V-0

GMSTB 2,5/ 4-ST-7,62
