1406240, Phoenix Contact Female 4 way M8 to Unterminated Sensor Actuator Cable, 2m, Кабельная сборка

Sensor/Actuator 4 Way Cable Assemblies, M8 Male or Female, Free End

M8 to free end connector cable assemblies, 4 way, angled or straight connector versions available with various lengths of PVC shielded yellow cable. A-coded connectors with a rating of 4A 30V, these M8 connectors are IP67 rated once mated.

100 mating cycles
Operating temperature range -25 to +90 °C
Surge voltage category II

Phoenix Contact Cable Assembly, M8 to Unterminated, 2m - SAC-4P- 2,0-542/M8 FS BK - 1406240

Supply your sensor or actuator with high-quality, reliable power using this Phoenix Contact cable assembly. It comes in a length of 2m, making it simple to connect equipment in your workspace.
Use the grooved metal nut on the standard M8 connector end to tighten it into place. This creates a secure connection that prevents signal loss and resists heavy vibrations. The unterminated cable end gives you the freedom to create a customised setup for your application.
This assembly is suitable for use in industrial environments thanks to its IP68 (ingress protection) rating, which means it's dust-proof and resistant to temporary submersion in water. The contacts are made from a copper-tin alloy that maintains high levels of conductivity while preventing corrosion, making this product a long-lasting and reliable choice.

Features & Benefits

• Straight body orientation for ease of connection
• Bright yellow sheath colour for quick identification in a complex set-up
• Durable polyvinyl chloride (PVC) sheath material resists abrasion and wear
• UV (ultraviolet) resistance to protect the wire from warping when exposed to sunlight

Sensor/Actuator cable - SAC-4P- 2,0-542/M8 FS BK
