1803688, Phoenix Contact 3.81mm Pitch 13 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

Phoenix Contact MINI COMBICON MC 3.81mm Pitch Terminal Block Plug Connectors

Phoenix brings you a series of MC PCB terminal connectors. Featuring a 3.81mm pitch and a well-known name, these connectors are brilliant. They allow a wire from 0.14mm² up to 1.5mm² with a simple screw connection with a tension sleeve and horizontal wire entry. Each connector can have a maximum of two connections with a rated current of 8A.

These terminal blocks allow you to transfer data, signals and power directly to your PCB safely. They make ideal use as permanent solution however can be used in temporary circuitry.

MINI COMBICON MC 3.81mm Features and Benefits:

•Maximum reliability due to high quality materials
•3.81mm pitch
•Screw connection with termination device to help prevent loosening of wire in high vibration
•Copper alloy contact material with tin plated terminal points
•-40°c to +70°c operating temperatures
•Height of only 8mm above the board for a small compact fit

These connectors use a M2 slotted (L) screw. If you need a screwdriver, check out “125-3078”

Other accessories:
•Marker cards – 648-5508
•Cable housing – 742-7409

Phoenix Contact Pluggable Terminal Block, Female, 8A Current Rating - MC 1,5/13-ST-3,81 - 1803688

Plug the gaps in your board-mounted setup with this pluggable terminal block from Phoenix Contact. As a 13-way unit, it juggles many circuits at once so it's easy to bring multiple appliances into contact. Tin-plated copper-alloy pins mean you can be confident of effective electrical connections to help send your signals in a flash. An 8A current rating means the connector keeps up with the flow of large electrical loads.
With its simple plug-in connection method, the block helps you power through the job hooking up your devices for fast system-building. Durable PA housing provides the insulation needed to avoid unpleasant shocks. As it accepts flexible and solid conductors with cross-sections between 0.14 and 1.5mm², this is a sure fit for your existing wiring. Don't worry about having to make space, as the connector's compact 3.81mm pitch lets it pack onto crowded circuit boards with minimal elbow room.

• Screws directly to PCBs, minimising disruption from vibration
• Broad operating temperature range between -40°C and +100°C, so it's suitable for intense industrial conditions
• Tested to IEC 60512-3-1 standards to ensure effective insulation
• Supplied in boxes of 50 for convenient stocking

MC 1,5/13-ST-3,81
