1827224, Phoenix Contact 3.81mm Pitch 12 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

Phoenix Contact MINI COMBICON MCVR & MCVW 3.81mm Plug-In Terminal Block Connectors

MINI COMBICON MCVR & MCVW 3.81mm pitch cable mount plug-in terminal block connectors with a 0.14 - 1.5mm² screw connection and 90° plug-in direction.
MCVR series terminal block connectors (part numbers prefixed with 18271, 18272, 18283, 18284) have the conductor entry facing the coding side. Part numbers prefixed with 18283, 18284 also have a screw flange.
MCVW series terminal block connectors (part numbers prefixed 18269, 18270, 18271, 18284, 18285, 18286) have the conductor entry facing the rippled side. Part numbers prefixed with 18284, 18285, 18286 also have a screw flange.
For marker label see stock number 648-5508
For screwdriver see stock number 390-9663

Phoenix Contact Mini 12-pin Plug-In Terminal Block, 3.81 mm Pitch - MCVR 1.5/12-ST-3.81 - 1827224

This Phoenix Contact mini plug-in terminal connector is designed to be used in measurement and control technology applications. Its 12-pin build is compatible with other printed circuit board components from the manufacturer's MCVR range.
The unit's screw-in connections let you safely wire conductors across a range of diameters. It has permanently low contact resistance to reduce fatigue on the wiring. A spring-loaded element prevents conductors from loosening themselves. The miniature size of this component allows you to compactly pack a circuit board, while its low profile helps it stay well-ventilated. This unit is manufactured from robust polyamide for a long service life. Its low operating temperature keeps circuit boards cool.
A connector such as this one stands up to the demands of harsh environments. It carries Underwriter Laboratories (UL) approval and has a UL 94-V0 rating, which means it's flame retardant and poses no risk of fire.

• Straight body orientation
• Current rating of 8 A
• Voltage rating of 320 V
• Female plug type
• Cable mounting type
• 12 contacts
• 1 row
• Pitch of 3.81 mm
• Dimensions of 46.51 (L) x 10.4 (W) x 19.1 mm (D)

MCVR 1,5/12-ST-3,81
