1827745, Phoenix Contact 3.81mm Pitch 6 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

Phoenix Contact MINI COMBICON MC 3.81mm Pitch Terminal Block Plug Connectors

Phoenix brings you a series of MC PCB terminal connectors. Featuring a 3.81mm pitch and a well-known name, these connectors are brilliant. They allow a wire from 0.14mm² up to 1.5mm² with a simple screw connection with a tension sleeve and horizontal wire entry. Each connector can have a maximum of two connections with a rated current of 8A.

These terminal blocks allow you to transfer data, signals and power directly to your PCB safely. They make ideal use as permanent solution however can be used in temporary circuitry.

MINI COMBICON MC 3.81mm Features and Benefits:

•Maximum reliability due to high quality materials
•3.81mm pitch
•Screw connection with termination device to help prevent loosening of wire in high vibration
•Copper alloy contact material with tin plated terminal points
•-40°c to +70°c operating temperatures
•Height of only 8mm above the board for a small compact fit

These connectors use a M2 slotted (L) screw. If you need a screwdriver, check out “125-3078”

Other accessories:
•Marker cards – 648-5508
•Cable housing – 742-7409

Phoenix Contact 6-Pin PCB Header, 3.81mm Pitch, 1 Row - MC 1.5/ 6-STF-3.81 - 1827745

This printed circuit board (PCB) header from Phoenix Contact allows you to join multiple wire-to-board connections on a single block. It's easy to connect as you just need to solder it directly onto a PCB and it's ready to use.
The unit has compact dimensions of 33.25 (L) by 11.1mm (D) and 16.1mm (W), so you can use it in setups where space is tight. It has six pins made of copper-alloy material that offers superior conductivity and ensures reliable connections. These contacts are plated with zinc for improved corrosion resistance, so you don't have to worry about rust.
The header has a polyamide (PA) housing material that provides impact resistance and is also an effective insulator, protecting you from electric shock. With a current rating of 8A and voltage rating of 320V, this component is suited to medium-power applications in industrial environments.

Features & Benefits

• UL94V-0 (Underwriters' Laboratory) flammability rating for fire safety indicates that burning stops within 30 seconds
• Screw-termination method for quick and easy installation
• Wide operating temperature range of -40°C to +70°C for use in demanding conditions

MC 1,5/ 6-STF-3,81

Line Drawing - 1827745
