TM3AI2HG, Schneider Electric FC4A Series PLC I/O Module for Use with Modicon M221, Modicon M241, Modicon M251, Current, Voltage, Модуль

Modicon TM3 - Analog Input Modules

Analog input modules for Modicon M221, M241 and M251 logic controllers

Modicon TM3 analog input modules
Types with different numbers of analog inputs
Types with voltage, current or temperature inputs available
Terminal block with screw or spring connectors

Schneider Electric PLC I/O Module, Spring Terminals, 2 Analogue Inputs - FC4A Series - TM3AI2HG

Channel extra process data into your control system with this PLC I/O module from Schneider Electric. It directly connects analogue components to a controller (806-6761), collecting sensor information to ensure precise machine management. With support for both current-based and voltage-based signal formats, the unit is widely compatible with standard measuring equipment. Connecting circuits is no issue thanks to its secure spring terminals. A response time of just 2ms means you can count on speedy system control.

Features & Benefits

• Repeat accuracy of ±0.5% means you can be sure of precise reading conversion
• 2 analogue inputs let you connect a pair of circuits to the unit
• Slim dimensions of 23.6 (W) x 90 (H) x 70mm (D) tuck neatly into busy systems
• Front-facing LED indicator clearly signals power status

Applications

• Food production
• Motor starters
• Aerospace engineering

How do I mount this module?

It snaps onto a standard DIN rail, so easily fits into a cabinet without the need for special tools.

Do I need a separate power supply for this device?

No, it takes power from its controller's supply, so there's no need for extra wiring.

Schneider Electric Modicon TM3

The Modicon TM3 is a MachineStruxure I/O system. The next generation of MachineStruxure from Schneider Electric is an intuitive solution for machine automation with all the features and functions you need to build machines that will improve your bottom line. From design and development, to commissioning and maintenance, MachineStruxure is a complete machine building solution with benefits all through the machine life cycle.
The Modicon TM3 expansion module offer provides an opportunity to enhance the capabilities of Modicon M221, M241 and M251 logic controllers.
In addition, the TM3 expansion system is flexible due to the possibility of remotely locating some of the TM3 modules in the enclosure or another cabinet (up to 5 meters away, using a bus expansion system.
