74099-0623, Molex SL Series Straight Surface Mount PCB Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Shrouded

SL Header, Surface Mount, Single Row, Vertical - 74099 Series

A range of Molex SL 74099 Series SMT single row Vertical Headers which are available with Gold or Tin plating on the mating area of the terminals as follows:
808-4270 3 way, Gold
808-4273 4 way, Gold
808-4277 6 way, Gold
808-4286 3 way, Tin
808-4289 6 way, Tin
For mating option G Housings see stock number 678-3152 typical.

Molex PCB Header, 2.54mm Pitch, Surface Mounting - SL Series - 74099-0623

Keep your circuit board on the straight and narrow with this PCB header from Molex. It has a TPA (terminal position assurance) retainer that increases its pullout force, which helps cut the chance of a terminal blackout. As the unit is insulated, you don't have to worry about electric shocks giving you a jolt during assembly. Soldering it to a board is a cinch, thanks to PCB retention pegs that firmly hold the header in position.

• Stackable low-profile housing for design flexibility
• Wide operating temperature range between -40˚C and +105˚C makes it suitable to use in demanding settings
• Gold-plated contacts support optimal electrical flow

Applications

• Factories
• Warehouses
• Industrial power supplies
• Hospitals and medical centres

Is this PCB header flame-retardant?

Yes, for your safety this component is flame-retardant. This means it only burns for a brief period in the event of a fire.
