1119804, Lapp ÖLFLEX CLASSIC 110 Control Cable, 4 Cores, 0.75 mm², YY, Unscreened, 50m, Grey PVC Sheath, 18 AWG, Кабель

Ölflex Classic 110

From Lapp, the Olflex Classic 110 YY Cable is a robust cable designed for use under medium mechanical stresses, such as power chain applications. The cable is suitable for fixed installation purposes, as well as those that require occasional flexing and movement.

This YY control cable consists of fine wire copper strands, with a special PVC conductor insulation and sheathing that is suitable for use in both dry and humid conditions. The cable also has a good resistance to chemicals and oils, making it ideal for challenging industrial environments.

YY cable is an excellent control cable solution for a variety of applications.

Features and Benefits

• Flame-retardant according to IEC 60332-1-2
• Oil-resistant according to DIN EN 50290-2-22 (TM54)
• Chemical resistance at room temperature
• Suitable for dry and humid applications
• Resistant to bending

Applications

Lapp Olflex Classic 110 YY cable is suitable for a wide range of uses, and is often used in control and measurement applications. It is suitable for some torsional applications, and as such is can be found in wind turbine generators. This unscreened YY cable has a robust and reliable nature makes it ideal for;

• Machine Tools
• Plant engineering
• Refrigeration plant sectors
• Construction Industries
• Transport
• Smart Homes

Accessories

Lapp cables should be used alongside accessories that match their capabilities. Lapp provides a variety of reliable and easy-to-fit cable glands, such as the Skintop Click series.

• 560-678 is an M12 IP68 Skintop Click Cable Gland
• 475-091 is an M16 IP68 Skintop Click Cable Gland
• 475-136 is an M20 IP68 Skintop Click Cable Gland
• 475-132 is an M25 IP68 Skintop Click Cable Gland
• 560-688 is an M32 IP68 Skintop Click Cable Gland

Standards

VDE, This cable confirms to ECD 73/23/EEC (low voltage directive).

LAPP Control Cable, 12A Current Rating, 6.2mm OD - ÖLFLEX CLASSIC Series - 1119804

Choose this 50m control cable from LAPP for long runs across your workplace. The PVC sheath is resistant to oil and chemicals, while the filler is non-wicking, so isn't affected by moisture. That makes this a durable and reliable choice for tough industrial environments. With a rated voltage of 300/500V, the cable is suitable for high-voltage industrial applications as well as household and consumer electronics.

• Four insulated cores to deliver multiple power and signal functions with minimal risk of crosstalk
• Operating temperature range from -40°C to +80°C, for use in harsh conditions
• Withstands occasional flexing for use with applications that go around corners or perform a limited repeated movement

Applications

• Machine tools
• Plant engineering
• Power chain installations

Is this product screened or unscreened?

This cable is unscreened, making it flexible, lightweight and easy to handle.

OLFLEX CLASSIC 110 Control Cable Data Sheet

Cable Selection Guide
