70S2-01-A-05-S, Schneider Electric 70S2 Series Solid State Relay, 5 A Load, Panel Mount, 60 V dc Load, 15 V dc Control, Реле

70S2 Series

70S2 series dc switching solid state relays specially designed for medium-power loads.

Optical isolation to protect the control from transients
Small package ideal for tight designs
Internal snubber for excellent transient protection
Screw, fast-on or PCB terminals depending on the model

Schneider Electric Solid State Relay, DC Switching, -40°C to +100°C Operating Temperature Range - 70S2 Series - 70S2-01-A-05-S

For super-quick power switching, put this solid state relay from Schneider Electric on your panel. When it receives a control signal, it swiftly flashes it across its internal transistor, turning the signal from electrical to optical. It takes just 75 microseconds to respond to an 'on' signal and 500 microseconds to switch off again. As the unit has no moving parts there's minimal risk of mechanical wear and tear. A load voltage range between 3 and 60V DC means it can handle medium-power loads.

Features & Benefits

• Input voltage range between 3 and 15V DC for versatile operation
• Wide operating temperature range of -40°C to +100°C
• Screw terminals achieve a secure electrical connection
• Integrated thermal management helps prevent overheating

Applications

• Data acquisition systems
• Robotic equipment
• Control panels

How do I install this relay?

Secure installation is done in a snap by soldering the units pins to your board.

What protective features does the relay have?

It comes with reverse polarity protection, so there's minimal risk of hazard if you install it incorrectly.
