THD 10-2411WIN, TRACOPOWER THD 10WIN DC-DC Converter, 5V dc/ 2A Output, 9 → 36 V dc Input, 10W, Through Hole, +85°C Max Temp, Преобразователь

Traco Power DC-DC Converter, 1000pF I/O Isolation Capacitance, Metal Casing - THD 10WIN Series - THD 10-2411WIN

Take control of energy delivery to your PCB-linked components with this DC-DC converter from Traco Power. It steps down input signals ranging between 9 and 36V DC, cleaning out noise with its internal filter to deliver a stable 5.1V DC output. For your peace of mind, it builds an isolation barrier of up to 1.5kV DC between the supply and output, preventing damage from unexpected voltage spikes. Thanks to a power rating of 10W, it's the one to call on for medium-duty applications. The metal casing protects the unit from impact and resists corrosion to handle installation in harsh environments.

Features & Benefits

• Light weight of 17.3g minimises board strain
• Mean time between failures of 1 million hours assures you of long-term performance
• Performs reliably in operating temperatures between -40°C and +85°C
• 87% efficiency means little energy is lost as heat

Applications

• Medical technology
• Process and packaging plants
• Renewable energy facilities

How big is this DC-DC converter?

The device measures 31.8 (L) x 20.3 (W) x 10.2mm (D), making it a space-efficient choice for busy setups.

Can I install this converter in humid environments?

Yes, it can withstand up to 95% relative humidity (non-condensing) without breaking a sweat.
