CHINFA DIN Rail Power Supply
The CHINFA DIN Rail DRE series switch mode power supply has a universal input voltage ranging between 88VAC and 264VAC with built-in active PFC. The switch mode technology provides a compact design, high efficiency and low residual ripple. The rated output current is 16A at 12VDC output voltage. This power supply is especially designed for industrial control systems, process automation and industrial applications requiring stabilised DC voltage.
Features and Benefits
150% for peak load capability
High efficiency of 91%
Internal input filter
MTBF is 452000 hours
Operation temperature ranging between -40°C and 71°C
Parallel function (switch selectable)
Power rating is up to 192W
Ripple factor and noise is 100mV
SELV components design
Short circuit protection
Applications
Electromagnetic drives
Factory automation
Industrial controls
Instrumentation
Certifications
CE certified
cUL
TUV
UL approved
DRE240 Series Datasheet
