THL 25-4812WI, TRACOPOWER THL 25WI DC-DC Converter, 12V dc/ 2.09A Output, 18 → 75 V dc Input, 25W, Through Hole, +80°C Max Temp, Преобразователь

Traco 25W Single/Dual Output Regulated Isolated DC-DC Converter - THL 25WI Series

The Tracopower THL 25WI comes in a metal case of very small dimensions, with high efficiency of up to 90% this isolated DC/DC converter is suited for use in temperature ranges of up to +80°C, or +85°C with optional mounted heat sink. The THL 25WI range of DC/DC converters feature a wide 4:1 input voltage range and precisely regulated output voltages. Typical applications of these DC/DC converters are in mobile equipments, instrumentation, distributes power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.

Highest power density 25W converter
Ultra compact design
Shielded metal case with isolated baseplate
Wide 4:1 input voltage ranges
Very high efficiency up to 90%
Output voltage adjustable
Remote On/Off control
Operating temperature range –40°C up to +80°C, +85°C with heat-sink
I/O isolation voltage 1500 VDC

Standards

UL/cUL 60950-1
IEC/EN 60950-1
