E5GC-QX2DCM-000, Omron E5GC PID Temperature Controller, 24 x 48mm, 1 Output Voltage, 24 V ac/dc Supply Voltage, Регулятор температуры

Omron Temperature Controller

The Omron E5GC series temperature controller has a supply voltage rating of 24VAC/DC. This high precision controller has a width of 48mm and a height of 24mm. It has a single voltage output for driving SSR and dual auxiliary outputs. The easy-to-read high contrast display with white characters and 10.5mm large characters is visible from large distances and any angle.

Features and Benefits

Alarm for loop break or PV change rate, heater burnout, or sensor burnout detection
Screwless clamp terminal
Easy connections to a PLC with program less communications
Easy connections to a PLC with program less communications.
Functions for diagnosis for secure operations
High-speed sampling at 50ms
PID temperature controller with auto-tuning
Set up the controller without wiring the power supply by connecting to the computer with a communications conversion cable (sold separately). Setup is easy with the CX-Thermo (sold separately)
Universal input
Universal input from TC, Pt sensors, analogy current and voltage

Applications

Laboratory instruments
Small equipment

Certifications

IP00 rated
IP20 rated
Overvoltage category II
Pollution degree 2 (EN/IEC/UL 61010-1)

Datasheet
