10-89-7402, Molex C-Grid Series Straight Through Hole Pin Header, 40 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded, Штыревой разъем

Molex C-Grid Unshrouded Pin Headers

Approvals

UL: E29179; CSA: LR19980

Molex Pin Header, High-Temperature Thermoplastic Housing, 3A Current Rating - C-Grid Series - 10-89-7402

Peg down conductors to your PCB using this pin header from Molex. With up to 40 circuits available in this two-way unit, you have enough space to set up a multiconductor wiring system on your board. It features highly conductive copper alloy contacts that ensure reliable power and signal feeds. The header has a robust thermoplastic body that stands up to heat in demanding settings. As it's stackable, you get the ability to build a block of headers with different levels on your board.

• Straight body orientation for easy front-facing mounting
• Gold contact plating resists corrosion in damp conditions
• Breakaway design enables flexible setup

Applications

• Instrumentation devices
• Control panels
• Robotics systems
• Communication networks

How durable is this pin header?

A durability rating of 50 mating cycles means this unit can be fastened and removed multiple times without suffering damage.

2.54mm Molex C-Grid/SL Series
