SYG1/LX-W/RF/W1, Eaton Series Red Sounder Beacon, 18 → 28 V dc, Wall Mount, 100dB at 1 Metre

Fulleon Symphoni LX Wall Sounder Beacon

The Symphoni LX Wall range of Sounder Beacons from Fulleon is ideal for applications that require both an audible and visual alarm. This sounder and beacon is a reliable, high performing VAD (Visual Alarm Device) that is certified to EN54-23. It is recommended for wall mounting and as the device combines a sounder and beacon it requires only one installation point for a single alarm system. Its high sound output makes this sounder beacon suitable for open areas or where there is higher than normal background noise. Not only is the Symphoni LX available as a dual alarm device but it is also available as a sounder base only unit, which can be used with any existing Symphoni sounders.

Features and Benefits

• Super-low current consumption sounder
• LED technology for long life and low current consumption
• Up to 7.5m coverage volume (switchable to 2.5m)
• 0.5 or 1Hz flash rate (switch to 0.5Hz to reduce current consumption)
• Delivering up to 100 decibels (dB(A)) sound output
• Suitable for use fire alarm systems and general signalling devices
• IP21C ingress of protection(WP version:IP66)
• White or Red body
• White or Red flashing LED Beacon

Note

Super low current consumption, can be retrofitted with existing Symphoni sounders including Symphoni High Output.

Standards

EN54-23.

Note

Eaton formerly known as Fulleon
