ILH-XC01-S410-SC211-WIR200. Intelligent LED Solutions, C3535 1 Powerstar Series UV LED, 420nm 440mW 125 °, 4-Pin, Ультрафиолетовый светодиод

8251590
Номер производителя: ILH-XC01-S410-SC211-WIR200.Производитель: Intelligent LED Solutions
Цена за шт.
3825.00 руб. (С НДС) *
Количество 2+ 5+
Цена 3579.00 руб. 3231.00 руб.

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Intelligent LED Solutions UV PowerStar, ILH-Xx01-Sxxx-SC211-WIR200 Series

The ILH-Xx01-Sxxx-SC211-WIR200 series, from Intelligent LED Solutions (ILS), are a family of compact and powerful UV LED arrays. The arrays consist of a TSLC LED mounted on to an ILS UV PowerStar board.
This family of UV LED arrays comes in a variety of TSLC LED options, all of which are compact, high quality and reliable. TSLC UV LEDs also offer a high radiometric power density and design flexibility.
Built on an aluminium substrate, the UV PowerStar arrays offer optimal thermal management. They have been designed primarily for industrial applications, for example; polymer curing, ink curing, counterfeit detection, aquarium lighting, medical and DNA sequencing and inspection equipment.

Features of the UV PowerStar family:
Variety of TSLC chip options
Mounting holes using M3 screws
200 mm connecting wires
PowerStars can be linked together to produce longer chains

TSLC LEDs and viewing angle:
C3535 - 125°
N3535 - 125°
N5050 - 65° or 135°
S5050 - 110°
T7070 - 65°
U9090 - 140°

Warning

UV LEDs emit ultraviolet light which can be hazardous to the human eye. Do not look at operating UV LEDs without necessary skin and eye protection.

TSLC UV LED Arrays

Техническая спецификация
pdfDatasheet
Высота:
3.5мм
Длина:
21мм
Количество светодиодов:
1
Количество штырьков:
4
Лучистый поток:
440мВт
Пиковая длина волны:
420нм
Размеры:
21 x 20 x 3.5мм
Серия:
C3535 1 Powerstar
Тип монтажа:
Поверхностное крепление
Угол обзора:
125 °
Форма линзы:
Куполообразная
Ширина:
20мм
