RS PRO 2-Axis Joystick Switch Knob, Spring Return, IP65 250V ac, Джойстик-переключатель

RS PRO, 2 Way Joystick Switch Knob, Spring Return, IP65 Rated, 250 V AC

From our reliable RS PRO range, this joystick switch allows for incredibly precise control when moving machinery. Consisting of a stick that pivots on a base, it's ideal for raising and lowering things and has multi-directional movement.

With an approximately 20° control range along its X and Y axes, this joystick switch is highly flexible. Couple this with a fast response time thanks to its spring return actuator and you get fine manipulation. With an IP65 rating, it's totally dust-tight and protected against water jets from any angle. This product will last for up to 200,000 operations and is panel mounted for effortless installation.

Part of our RS PRO series, it has been stringently tested to ensure its toughness and reliability. This joystick switch can control the movement of machinery, such as cranes and trucks, especially in areas where there is potential for dirt and water contamination.

Features and Benefits

• Two axes with a joystick travel tolerance of ±12°
• Spring return switch
• Quick-connect terminals
• Contact voltage rating of 250 V AC
• Contact current rating of 5 A at 250 V AC
• Operating temperature range of -20°C to +65°C
• Depth behind panel of 21.5 mm
• Knob handle with a height of 37 mm
• Mechanical life of 200,000 operations
• RoHS (Restriction of Hazardous Substances) compliant so no hazardous substance is present in excess of 0.1%
• IP65 rated for total ingress protection from dust and powerful water jets from any angle

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS Pro Datasheet
