RS PRO Brushed Geared DC Geared Motor, 7.85 W, 12 V dc, 2399 gcm, 228 rpm, 6mm Shaft Diameter, Двигатель

RS PRO, 12 V dc, 2399 gcm, Brushed DC Geared Motor, Output Speed 228 rpm

Looking for a motor that's efficient at low speeds but still provides a high starting torque? These 12 V DC geared motors come complete with a planetary gearhead that enhances torque while optimising efficiency for low-speed operations.

Like all products from the RS PRO range, these motors boast high-quality construction from premium materials. The gears have sturdy sintered bronze bearings that are self-lubricating, meaning they reduce friction and require less maintenance. The motors use a brush to deliver current to the motor windings, which helps ensure smooth motion at lower speeds. Thanks to their robust construction, each DC geared motor can withstand prolonged use in heavy-duty environments despite their compact size and weight. They have iron cores that act as heat sinks, so they're less prone to temperature overloads.

Planetary geared motors are useful for both industrial and modelling applications. You'll find them used for everything from automation and robotics to massage chairs and golf carts.

Features and Benefits

• Brushed DC motors with a planetary gearhead
• Output speed of 228 rpm
• Maximum output torque of 2399 gcm
• Supply voltage of 12 V DC
• Current rating of 990 mA
• Power rating of 7.85 W
• Shaft diameter of 6 mm
• Length of 73.9 mm
• Width of 32 (Dia.) mm
• Weight of 213 g
• Iron core

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

RS PRO Datasheet
