RS PRO 3 Core 1.5 mm² Mains Power Cable, Cross-Linked Compound, Type EM 8 to EN 50363-6 Sheath 100, 750 V, H07ZZ-F

H07ZZ-F LSZH Cable

This H07ZZ-F harmonised cable is manufactured with a low smoke zero halogen (LSZH) sheath. It is installed where fire, smoke emission and toxic fumes create potential threats to life and equipment. Applications include supplying mobile power units, UPS installations, stage technology and audio visual equipment.

Features and Benefits

• Low smoke zero halogen sheath and insulation
• Able to withstand mechanical stress
• Suitable for indoor or outdoor installation

Standards

EN 50525-3-21, CENELEC HD22-13, CEI 20-19 Part 13, BS EN/IEC 60332-3, BS EN 60228, EN 50363

RS PRO 3 Core 1.5 mm² Mains Power Cable, Cross-Linked Compound, Type EM 8 to EN 50363-6 Sheath 100 m, 750 V, H07ZZ-F

This three-core mains power cable from the RS PRO range is used in installations where the risk of fire, smoke emission and toxic fumes could threaten life and equipment. As a low-smoke, zero-halogen cable, it minimises the risk of dangerous emissions in the event of a fire.

The cable is safe to use at temperatures up to +90˚C. It's available in lengths of 100 metres, has an outer diameter of 9.2 mm to 11.9 mm and a cross-sectional area of 1.5 mm².

This product has been stringently tested against international standards on low-smoke and zero-halogen emissions, including CENELEC HD22-13, CEI 20-19 Part 13, BS EN/IEC 60332-3, BS EN 60228, EN 50363 and TS EN 50525-3-21. It's also RoHS compliant, so it contains minimal amounts of hazardous substances.

The cable can be installed indoors or outdoors. Applications include supplying mobile power units, UPS installations, stage lighting and audio-visual equipment.

Features and Benefits

• Low-smoke, zero-halogen cable
• Three-core cable
• 100-metre reel
• Stranded cable with a flexible PVC sheath
• Resistance of 13.3 Ω/km
• Voltage rating of 750 V
• Outer cable diameter of 10.2 to 13.1 mm
• Maximum operating temperature of +90˚ C
• Compliant with a wide range of international standards on low smoke and zero halogen emissions.

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
