RS PRO 2 Core Power Cable, 4 mm², 100m, White, Fire Performance, 500 V, Кабель

RS PRO 2-Core H05Z1Z1-F Power Cable, White, 100 m, 500 V

Use this RS PRO power cable for all of your indoor wiring requirements. It has two cores so it's suitable for double-insulated appliances that don't require earth cores.
This robust cable is LSZH (low smoke zero halogen). This means it won't release toxic halogen fumes in the event of fire, making it safe for use in public places. The sheath material is a flame-retardant thermoplastic that also protects the product from damage, increasing durability.
The cable has a length of 100 m, so it can greatly extend the distance between a power source and your appliances. Cables like this are ideal for use in populated and enclosed areas, such as hospitals, train stations and airports.

Features and Benefits

• Wire size of 11 AWG (American Wire Gauge)
• Low smoke zero halogen (LSZH) cable type
• Copper conductor material
• Conductor resistance of 4.95 Ω/km
• Cross-sectional area of 4 mm²
• Flame retardant
• H05Z1Z1-F harmonised code, indicating superior fire safety
• Thermoplastic insulation material
• Length of 100 m
• Operating temperature range of -5°C to +70°C
• Two cores
• Five strands
• Outer diameter of 9.7 to 12.1 mm
• Reference of 3182B
• Indoor series
• White sheath colour
• Strand size of 0.3 mm
• Meets BS EN 50525 standards for power cables for domestic and industrial appliances
• Voltage rating of 500 V
