RS PRO Dark Blue 0.75 mm² Hook Up Wire, 18 AWG, 22/1.0 mm, 100m, Polyolefin Cross-linked EI5 Insulation

RS PRO Dark Blue Equipment Wire, 0.75 mm², 100 m

Use this versatile equipment wire from the RS PRO range for ducts, pipes and the internal wiring of appliances. It has a flexible copper core and is suitable for installation in a variety of sockets, circuit boards and electrical appliances.


The jacket of the cable is made from a polymer material that's cross-linked, meaning it's molded using both pressure and heat. This ensures the insulation has a greater resistance to cutting, corrosion and cracking, making this a long-lasting product.


The cable sheath has an impressive heat resistance and can withstand temperatures up to +90°C. As it's a low smoke zero halogen (LSZH) material, it won't create toxic fumes or high levels of smoke if there's a fire. This makes the cable safe to use in heavily populated places.

Features and Benefits

• Wire size of 18 AWG (American Wire Gauge)


• Round cable shape


• Copper conductor material


• Core strand size of 1 mm


• Cross-sectional area of 0.75 mm²


• H05Z-K harmonised code for low-voltage flexible cables


• Polyolefin cross-linked EI5 insulation material


• Insulation wall thickness of 0.6 mm


• Length of 100 m


• Operating temperature range of -5°C to +90°C


• 22 strands


• Outer diameter of 2.8 mm


• Dark blue sheath colour


• Meets Euroclass Eca fire safety standards


• Equipment wire type


• Voltage rating of 500 V

Datasheet 8360779

Cable Selection Guide

RS PRO Wiring and Connectivity Selection Guide 2021
