RS PRO Red 0.75 mm² Hook Up Wire, 18 AWG, 22/1.0 mm, 100m, Polyolefin Cross-linked EI5 Insulation

RS PRO Red Equipment Wire, 0.75 mm², 100 m

Need a durable equipment wire for internal wiring applications? This product from RS PRO is designed for use in household electrical appliances and with pipes and ducts. The flexible copper core within the wire makes it a versatile product as it can be installed in a range of sockets and circuit boards.


The cross-linked polymer material of the cable's jacket has been molded by pressure and heat for increased resistance to corrosion, cutting and cracking. This makes the wire more durable and ensures a long service life.


This cable sheath can be used at temperatures up to +90°C thanks to its impressive heat resistance. It's also a low smoke zero halogen (LSZH) material, so it won't produce toxic fumes or excess smoke in the event of a fire. This makes the cable safe to install in crowded areas.

Features and Benefits

• Wire size of 18 AWG (American Wire Gauge)


• Round cable shape


• Copper conductor material


• Core strands of 1 mm


• Cross-sectional area of 0.75 mm²


• H05Z-K harmonised code for low-voltage flexible cables


• Polyolefin Cross-linked EI5 insulation material


• Insulation wall thickness of 0.6 mm


• Length of 100 m


• Operating temperature range of -5°C to +90°C


• 22 strands


• Outer diameter of 2.8 mm


• Red sheath colour


• Meets Euroclass Eca fire safety standards


• Equipment wire type


• Voltage rating of 500 V

Datasheet 8360785

Cable Selection Guide

RS PRO Wiring and Connectivity Selection Guide 2021
