89761-3412, Molex Female SMA to Female U.FL Coaxial Cable, 100mm, Terminated, Кабель

Molex female SMA to female U.FL coaxial cable

Leading electronics manufacturer Molex Incorporated presents its female SMA to female U.FL coaxial cable range. With an impedance rating of 50Ω, this high-quality cable provides customers with an excellent and essential solution for a variety of cable connection needs.

The product comes supplied with a gold plated brass jam nut and gold-plated lock washer. The coaxial cable also features a terminated end, allowing quick and easy connection to a range of applications.

Features and Benefits:

Dual-ended connectors as part of its configuration,

• SMA-to-MCRF plug assembly,


• Gold plating mating for high reliability and low voltage,


• Net weight - 4g,


• Cable length - 100mm,


• Cable diameter – 1.13mm.

Applications:

• Connecting radio transmitters and receivers to antennas,


• Connecting broadband routers to the supplier network,


• Feeding signals through to your television.

What are SMA and MCRF?

SMA or SubMiniature Version A refers to this products connector. SMA connectors come in a range of different formats such as male, female, straight, right-angled, etc…
MCRF or Micro Coaxial RF are ultra-microminiature wire-to-board solutions that are ideal for small handheld wireless devices.

What is Impedance?

Impedance is an electric current’s opposition being measured when the voltage has been applied.

Please refer to the technical drawing for further information.

Molex Gold-Plated SMA to MCRF Coaxial Cable, 100m - 89761 Series - 89761-3412

Protect radio frequency transmission from damaging external interference with this reliable Molex coaxial cable. It features multiple protective layers that shield the inner cable from harsh environments. Operation is via a pair of female SMA (subminiature version A) to MCRF (micro coaxial radio frequency) connectors, making this an ideal choice small systems. The brass jam nut is gold-plated, ensuring optimal electrical conductivity and high resistance to corrosion. You can use this coaxial cable to transmit electrical signals across a wide range of devices.

• 100m cable for easy connectivity between devices
• Low weight of 4g for easy handling
• Female-to-female dual-ended connectors for use in diverse applications
• Phosphor bronze material ensures reliable performance in high-temperature systems

Applications

• Antennas
• Video display systems
• Audio networks
• Network equipment

How does an SMA to MCRF plug function in this coaxial cable?

The SMA connector allows for precise insertion and durable performance in small systems. The MCRF is compact and has a snap-on mechanism, so it's convenient for use in miniature, wireless installations. Both connectors ensure optimal performance in installations with an impedance rating of 50Ω.

Molex RF Coaxial Cable Assemblies

SMA Jack-to-MCRF Plug Assembly Datasheet

Drawing
