1182-3/4\, 3M 1182 Conductive Tin Clad Copper Tape, 19.1mm x 16m, Медная лента

3M™ Copper Foil Shielding Tape 1182

The Copper foil shielding tape 1182, has a 1.4-mil copper foil backing, a conductive acrylic pressure sensitive adhesive on both sides, and a liner.

Features and Benefits:

• EMI Copper foil shielding tape
• Deadsoft 1-ounce copper foil backing
• Double-coated conductive adhesive makes an excellent conductive gasket

Applications:

Used to bond 2 surfaces together, both electrically and physically, such as EMI shielding, grounding and static charge draining.

Why choose 3M?

3M are a trusted name in tapes and adhesives solutions. From industrial and electronic applications to meeting domestic requirements, 3M supply high quality and reliable tapes and adhesives. RS Components partners with 3M to deliver an extensive and inclusive range of excellent 3M products, with the fantastic and convenient consumer service our customers rely on.

Similar 3M Tapes within this Range

• 110-8054 is a 3M 1181 Conductive Copper Tape, 12.7mm x 16m
• 167-9376 is a 3M 1181 Conductive Copper Tape, 50.8mm x 16m
• 842-0360 is a 3M 1182 Conductive Tin Clad Copper Tape, 19.1mm x 16m
• 842-0409 is a 3M 1183 Conductive Tin Clad Copper Tape, 19.1mm x 16m
• 842-0364 is a 3M 1194 Non-Conductive Tin Clad Metallic Tape, 19.1mm x 33m
• 842-0370 is a 3M 1267 Conductive Metallic Tape, 25.4mm x 16m
• 842-0367 is a 3M 1345 Conductive Tin Clad Metallic Tape, 19.1mm x 16m

3M Conductive Tin Clad Copper Tape, 19.1mm (W) x 16m (L) - 1182 Series - 1182-3/4"X18YD

When you're looking for a reliable and user-friendly tape to bond two surfaces together both electrically and physically, this copper foil shielding tape from 3M is an effective solution. It consists of a 1.4mm copper foil backing with a conductive acrylic pressure-sensitive adhesive on both sides. The adhesive contains highly conductive particles that provide multiple electrical paths between the application substrate and the surface of the copper foil. This means you can use it to create an efficient EMI (electromagnetic interference) shield for an electronic enclosure.

• Tensile strength of 44N/cm for durability and flexibility of use• Adhesion strength of 3.8N/cm for a firm and reliable hold• Supplied with a removable liner on both sides to enable easy cutting and handling• Conductive on both sides meaning electrical connections can be made by taping two lengths together

Applications

• Grounding and EMI shielding in equipment• Shielded rooms• Protecting sensitive components

What's electromagnetic shielding?

Electromagnetic shielding involves using conductive or magnetic materials to block an electromagnetic field from entering a space. It can be used to isolate electrical devices from their surroundings and prevent damage to sensitive components.

EMI/RFI Shielding Tapes

When using these tapes galvanic compatibility should be taken into account.

3M Copper Foil Tape 1182 - Datasheet
