278728 FAZ-B6/2, Eaton xEffect MCB, 2P, 6A Curve B, 240 → 415V AC, 60V DC, 10 kA Breaking Capacity

Eaton FAZ Series Circuit Breakers

The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eaton’s FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.

Features and Benefits

• The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.

Eaton 2-Pole MCB, 6A Current Rating, B Curve - FAZ Series - 278728 FAZ-B6/2

Features & Benefits

• Nylon housing resists corrosion, so is suitable to use in moist environments
• Mechanical lifespan of up to 10,000 operations for consistent reliability throughout its extended service life
• Re-usable for efficiency, as there's no need to replace any part of the unit after it's tripped

Is this MCB UL approved?

Yes, this MCB meets UL1077 standards for supplementary protectors used in appliances and electrical equipment where branch circuit protection isn't needed or where this protection is already provided.

What's the breaking capacity of this MCB?

This MCB has a breaking capacity of 10kA for compatibility with domestic and light-industrial circuits.

Note

Eaton formerly known as Moeller
