102253 FAZ-C30/3-NA, Eaton xEffect MCB, 3P, 30A Curve C, 240 → 415V AC, 10 kA Breaking Capacity

Eaton FAZ Series Circuit Breakers

The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eaton’s FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.

Features and Benefits

• The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.

Eaton 3-Pole MCB, 30A Current Rating, C Curve - FAZ Series - 102253 FAZ-C30/3-NA

Features & Benefits

• Wide operating temperature range between -40°C and +75°C for compatibility with extreme conditions
• Conforms to IEC 60947-2 standards for low-voltage circuit breakers, for assured safety
• Easy to snap onto a DIN rail for quick installation
• Status indicator for convenient visual inspection

Is this MCB suitable to use with fluorescent lighting circuits?

Yes, this C-curve circuit breaker is specifically designed for high inductive loads where start-up surges are substantial, like fluorescent lighting systems and small motors.

Can I use this MCB in place of a fuse?

Yes, you can use this MCB in place of a fuse in equipment where branch circuit protection is already provided or not needed.

Note

Eaton formerly known as Moeller
