278753 FAZ-C5/2, Eaton xEffect MCB, 2P, 5A Curve C, 240 → 415V AC, 10 kA Breaking Capacity

Eaton MCB, DIN Rail Mounting, 60Hz Maximum Frequency - FAZ Series - 278753 FAZ-C5/2

Struggling to protect sensitive equipment against electrical faults? This MCB from Eaton gives you a break. It opens a circuit in the event of an overload to stop dangerously high currents from damaging downstream components. Thanks to the unit's two-pole construction, it can handle hefty voltages of up to 415V AC. As it's a type C device, it trips when it receives between five and ten times its 5A current rating. This means you can use it with confidence in high-powered applications that experience brief surges, like fluorescent lighting installations, control circuits and electric motors. For added safety, the trip-free design means you can't keep the circuit open by holding the breaker in the on position.

Features & Benefits

• Colour-coded contact position indicator offers at-a-glance status information
• IP20 rating indicates the unit's touch-proof so keeps you safe from shocks if you accidentally touch it when it's powered up
• Captive screws can't be lost so there's no more chasing after dropped fastenings
• Wide operating temperature range of -40°C to +75°C for use in harsh conditions

What size is this MCB?

This device has compact dimensions of just 85 (W) x 36 (L) x 73mm (D), so it fits comfortably into crowded control cabinets.

Note

Eaton formerly known as Moeller
