278878 FAZ-C50/3, Eaton xEffect MCB, 3P, 50A Curve C, 240 → 415V AC, 10 kA Breaking Capacity

Eaton FAZ Series Circuit Breakers

The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eaton’s FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.

Features and Benefits

• The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.

Eaton 3-Pole MCB, 50A Current Rating, C Curve - FAZ Series - 278878 FAZ-C50/3

Features & Benefits

• Lifespan of up to 10,000 operations for consistent reliability
• Wide operating temperature range between -40°C and +75°C, so withstands the demands of extreme conditions
• Captive screw terminals to reduce the chance of you losing screws when they're undone
• Suitable for international use as it meets IEC 60947-2 safety standards for low-voltage circuit breakers

What material is this MCB's housing made from?

This MCB has nylon housing to protect it against dirt and moisture. The robust enclosure also protects against abrasion and bumps to extend the breaker's life in harsh operating environments.

Note

Eaton formerly known as Moeller
