278754 FAZ-C6/2, Eaton xEffect MCB, 2P, 6A Curve C, 240 → 415V AC, 10 kA Breaking Capacity

Eaton FAZ Series Circuit Breakers

The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eaton’s FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.

Features and Benefits

• The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.

Eaton Miniature Circuit Breaker, 6A, 240 to 415V AC - FAZ Series - 278754 FAZ-C6/2

Protect your control circuits with this supplementary MCB (miniature circuit breaker) from Eaton. It's a 2-pole device with a tripping characteristic type of C, so it trips at 5 to 10 times the rated current. A bimetallic thermal release protects against overcurrent, making this fuse useful in commercial and industrial applications with a high chance of short circuits. Its current-limiting design has the highest class of 3, so it quickly interrupts short circuits to protect your system. Use the DIN rail clip to easily mount it on your panel to keep your transformers, coils and large appliances operating safely.

• Trip-free design means fault detection can't be manually overridden by holding the toggle in the 'on' position, increasing workplace safety
• Rated voltage between 240V AC and 415V AC means it's compatible with medium-power circuits found in industrial and commercial applications

How easy is this MCB to use?

This MCB is designed for ease of use. Each terminal is labelled ready for connection and it has captive screws that won't get lost during installation and maintenance. Red and green indicators make the circuit status clear at all times.

Note

Eaton formerly known as Moeller
