216571 M22-CLED-G, Eaton M22 Series Light Block, 12 → 30V ac/dc, Green Light, Световой блок

Eaton Light Block, 5A Operating Current, Green LED - M22 Series - 216571 M22-CLED-G

Want to illuminate your push button head? Brighten things up with this 12 to 30V Eaton light block. It's a modular unit that works with a switch and contact block. The green LED glows when the button is pressed, letting you know when an attached device is energised. Thanks to its IP20 rating, you can be sure that the block is touch-proof and protected against small objects larger than 12mm. Devices like this one can be found in medical and testing equipment, as well as domestic appliances and electronics.

Features & Benefits

• Electrical lifespan of 100,000 hours at a +25°C operating temperature, so it's reliable
• Operating temperature range between -25°C and +70°C assures you it's suitable for use in harsh environments
• Works with AC and DC systems for wide compatibility
• Mountable in any position to suit the needs of your setup

Can this product withstand impulse voltages?

Yes, it can. The light block has been tested up to 6000V AC, so it has proven protection against sudden impulse voltages.

What wire sizes is this unit compatible with?

This versatile light block is compatible with electrical conductors in a wide cross-section range between 0.5 and 2.5mm².

Note

Eaton formerly known as Moeller

Datasheet

Installation Sheet - RMQ-Titan

Brochure - RMQ Pilot Devices

Catalogue - Pilot Devices, Signal Towers, Position Switches
