QS30EX, Banner Through Beam Photoelectric Sensor, Barrel Sensor, 213 m Detection Range, Фотоэлектрический датчик

WORLD-BEAM QS30 Series

The WORLD-BEAM QS30 series of photoelectric sensors from Turck Banner are a high performance series of sensors that are easy to use and offer a variety of configuration options that make these sensors suitable for demanding applications.
The QS30 series offer an innovative housing that is designed to suit almost any mounting requirement and has a IP67 or IP69K environmental rating (depending on model).
Models with standard 10 to 30V dc supply voltage and bipolar NPN/PNP outputs or 24 to 250V ac/12 to 250V ac supply voltage with e/m relay output.
The QS30 series is available in opposed, high-power opposed, polarized, non-polarized retro-reflective, diffuse, laser, fixed-field and adjustable-field sensing modes.

Bright LED operating status indicators visible from 360°
High-power sensing with ranges up to 200m
Light or dark operate selectable or configurable (depending on model)

Banner Photoelectric Sensor, IP67 Rating, 30mm Barrel Diameter - WORLD-BEAM QS30 Series - QS30EX

Looking to quickly spot errors in your automated setup? Hand the task to this Banner photoelectric sensor. By pairing it with a receiver (847-9568) to check the size and shape of objects, the unit's through-beam function takes searching for process flaws off your hands. With its 213m detection range, the device reaches far to scan products in deep-lying areas. Hooking it up is a cinch, thanks to its industry-standard M30 connector. As the sensor reacts in just 30ms, it catches issues in fast-moving processes for reliable sensing.

Features & Benefits

• IP67 rating indicates protection against dust and temporary water submersion, staying strong in harsh settings
• Invisible infrared laser to minimise distraction during operation
• Takes supply voltages between 10 and 30V DC for wide power source compatibility
• Cable length of 2m provides flexible layout options
• Durable ABS casing for effective impact resistance

Applications

• Food production
• Warehouses and loading bays
• Distribution centres
• Factories

How do I know if the device is working properly?

The sensor features LED indicators on its top and rear sides, so it's easy to check its power and output status at a glance.
