TRACOPOWER Switching Power Supply, TXM 150-124, 24V dc, 6.3A, 150W, 1 Output, 90 → 264V ac Input Voltage, Источник питания

Traco Power Switching Power Supply, 150W Power Rating, 24V DC Output Voltage - TXM 150 Series - TXM 150-124

Keep your electrical equipment safe and sound with this switching power supply from Traco Power. It helps protect your devices against unstable voltages by converting an input voltage between 90 and 264V AC (or 120 and 370V DC) to a steady output voltage of 24V DC. Screw terminals ensure secure speedy wiring without the need for special tools. A power rating of 150W means you can rest assured this unit is suitable for use in heavy-duty systems. To boost safety, it comes complete with built-in short-circuit protection.

Features & Benefits

• Efficiency of 88% ensures minimal energy waste
• Surge voltage up to 300V AC for five seconds to prevent electrical damage

Applications

• Robotics systems
• IT equipment
• Industrial automation

How reliable is this device?

Thanks to an MTBF of 200,000 hours at +25°C, you can count on it to stay the course.

Can I use this switching power supply in extreme environments?

Yes, a wide operating temperature range between -20°C and +70°C means it can stand up to use in harsh environments.
