1828935, Phoenix Contact 7.62mm Pitch 4 Way Pluggable Terminal Block, Inverted Header, Through Hole, Solder Termination

Phoenix Contact COMBICON GICV 2,5 Series 7.62 mm Pitch Inverted Terminal Block Headers

COMBICON GICV 2,5 Series 7.62 mm pitch inverted terminal block headers which form part of a two-part pluggable terminal block system. These headers offer design flexibility as they can be used with inverted GIC series plug connectors for wire to board connections and GMSTB 2,5 headers for board to board connections. The vertical connection orientation enables space saving multiple row mounting on the PCB. These design of these headers provides a clear separation of PCB inputs and outputs and are suitable for use in shock proof applications up to 630 V (III/2)

Features and Benefits

• Mate with inverted plugs and headers for wire to board and board to board applications
• Vertical orientation for PCB space saving
• Clear separation of PCB inputs and outputs
• Suitable for use in shock proof applications up to 630 V (III/2)

Phoenix Contact COMBICON 7.62mm Two Part Terminal Blocks

Approvals

UL94V-0
