HTB-44I-R, Eaton 20A Panel Mount Fuse Holder for 6.3 x 32mm Fuse, 1P, 250V ac, Держатель предохранителя

Eaton Panel Mount Fuse Holder, Tin-Plated Contact Material, Manual Cap - HTB Series - HTB-44I-R

Don't let short circuits trip you up – help protect your kit with this panel mount fuse holder from Eaton. It's designed to securely hold a standard 6.3 (diameter) x 32mm (length) fuse that protects your circuits if overcurrent occurs. The holder mounts into your setup by simply slotting into an electrical control panel or enclosure. This enables easy positioning and replacement of fuses in areas that would otherwise be hard to reach. Fuse holders like this one are most commonly used in automotive electrics, industrial control panels and engineering applications.

Features & Benefits

• Quick-connect terminals for speedy installation
• 20A current rating suitable for mid-current to high-current applications
• Manual cap for convenient removal and replacement of fuses
• 250V AC voltage rating for heavy-duty circuit protection

What are the contact materials of this fuse holder made of?

The contacts are made of tin-plated brass, for resistance against corrosion and safe use in harsh industrial environments.

Can this holder handle high temperatures?

Yes, it's made of a thermoplastic material that copes with high temperatures. It's also flame-retardant, so won't contribute to a workplace fire.

Note

Eaton formerly known as Bussmann

Panel Mounting

CATEGORIES OF PROTECTION AGAINST ELECTRIC SHOCK,PC1: No integral protection against electric shock. If required, designers must provide additional protection against electric shock on equipment.,PC2: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 standard test finger, when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.,PC3: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 1mm diameter rigid test wire when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.

Datasheet

Transition to Bussmann Series
