9S0924F4011, Sanyo Denki San Ace 9S Series Axial Fan, 24 V dc, DC Operation, 76m³/h, 2.16W, 90mA Max, 92 x 92 x 25mm, Вентилятор

San Ace Silent DC Fans - S Series

Sanyo Denki San Ace silent DC fans are the lowest audible noise ball bearing DC fans available, with a reduction of up to -6dB when compared to standard fans. San Ace silent DC fans also feature excellent airflow and static pressure performance due to a new impeller and motor design.

50% reduction in vibration with precision dual ball bearing motor and fan blade balancing
Reduced switching noise at low speed compared to other DC fans
3rd wire pulse sensor for monitoring fan speed as standard
Airflow and noise level specification guaranteed over the life of the fan
Life at 40°C ambient 67,000 hours continuous operation (fan mounted in any position)
ECO product

Approvals

UL, CSA, TUV

Sanyo Denki Axial Fan, 24V DC, 2650rpm - San Ace 9S Series - 9S0924F4011

For effective ventilation of your industrial and commercial equipment, choose this axial fan from Sanyo Denki. It helps to keep your equipment cool and prevent the buildup of dust and lint for improved system performance. It features a dual ball bearing mechanism that reduces vibration and friction for reduced wear and noise. Thanks to its low sound output of just 27dB, this unit is a good choice for use in quiet work environments. As it consumes just 2.16W of power, it's an energy-efficient cooling solution.

Features & Benefits

• Long mechanical lifespan of 40,000 hours for long-term performance
• Compact dimensions of 92 (height) x 92 (width) x 25mm (depth) for installation in setups with limited space
• Broad operating temperature range of -10°C to +70°C for use in harsh conditions
• Plastic body and impeller blades for resistance to impact and abrasion
• Current rating of 0.09A for use in low-power systems

Applications

• Gaming consoles
• Refrigeration systems
• Machine power units

What's the air flow rate of this fan?

This fan has a high air flow rate of 75.6m³/h, making it a powerful device for efficient cooling.
