9CRA0848P8G001, Sanyo Denki San Ace 9CRA Series Axial Fan, 48 V dc, DC Operation, 270m³/h, 63.4W, 1.32A Max, 80 x 80 x 80mm, Вентилятор

San Ace Counter Rotating DC Fans - CR Series

Sanyo Denki CR series counter rotating DC fans feature exceptional levels of air flow and static pressure due to the back-to-back fan configuration. The long life, space optimising design of the CR series makes these fans suitable for a wide variety of demanding applications.

Sanyo Denki Axial Fan, 48V DC, 270m³/h Air Flow - San Ace 80 CRA Series - 9CRA0848P8G001

Keep your equipment cool with this axial fan from Sanyo Denki. It helps prevent overheating to ensure the optimal performance of your machinery. This unit features a robust back-to-back fan configuration for effective rotation. A maximum air flow of 270m³/h means it moves a large volume of hot air for effective ventilation. Thanks to its wide operating temperature range of -10°C to +70°C, it's suitable for use in demanding industrial environments.

Features & Benefits

• Current rating of 1A for use in low-power applications
• Robust mechanical service life of 40,000 hours at +60°C and 70,000 hours at +40°C for long-lasting performance
• Built-in ball bearing to reduce friction in heavy-duty applications
• Combined PWM (pulse-width modulation) and tachometer sensor for efficient moderation of fan operation

Applications

• Energy industry
• Telecommunications
• Medical equipment
• Automotive industry

How fast does this fan rotate?

It has a rotation speed of 12,000rpm on its inlet side and 11,300rpm on its outlet side. This means you can rely on this axial fan for applications that require quick and constant cooling.

Sanyo Denki 9CRA0848P8G001 Counter rotating fan datasheet
