3044671, Phoenix Contact UTT 2.5-2MT-P/P BU Series Grey Knife Disconnect Terminal Block, Screw Termination

UT Double-level Disconnect and Knife Disconnect Terminal Blocks

The UT screw terminal block series from Phoenix Contact combines the advantages of screw connection technology with the benefits of spring-loaded contacts.
They have a standard disconnect zone in the upper level and a double function shaft in the lower level. The UTTB terminal blocks also offer a level offset. If fully wired, it gives full access to the lower connection level and a perfect view of the lower labelling markers and conductor entry funnel.

Features and Benefits

• Each terminal point supports large surface labelling
• Convenient separation of circuits, thanks to lever-type disconnect knife
• Two separate potentials can be routed side by side with the help of bridging between non-adjacent terminal blocks (866-6807 and 866-6816)
• Test socket screws for insertion of test plugs (except 866-6847)
• RoHS compliant

Standards

IEC 60947-7-1, V0 UL94 flammability rating.

Approvals

UL, cUL, EAC, CSA, cULus.

Phoenix Contact CLIPLINE UT Range

Datasheet
