750-612, Wago 750 Series PLC Power Supply for Use with I/O Module, 5 V dc, Блок питания

Wago PLC Power Supply, 230V AC/DC Voltage Rating, 10A Current Rating - 750 Series - 750-612

Bring your PLC components to life with this power supply from Wago. It keeps your controller's connected I/O modules ticking along. The unit clasps onto connecting wires in a snap and doesn't let go, thanks to the cage clamp system. As it has a wide operating temperature range between 0°C and +55°C, this device is primed and ready for use in demanding environments. Use it to quickly boot up actuators, sensors and switches to expand your industrial system's capabilities.

Features & Benefits

• Slim dimensions of 100 (H) x 12 (W) x 69.8mm (D) to fit into tight spaces
• Mounts onto a standard 35mm DIN rail for speedy installation in your existing system
• IP20 rating indicates it's finger-safe and protected against objects larger than 12mm in size

Applications

• Automated systems
• Manufacturing sector
• Aerospace engineering

What can I do if I need more current capacity?

If you need a higher current capacity than 10A, add another intermediate supply module like this one to your assembly.

How much wire should I strip before inserting it into this power supply?

You'll need to strip 28 to 14AWG-sized wires between 8 and 10mm to get a good connection.

Wago I/O system range

Remote I/O modular system for all functions.
Makes it easier to connect all I/Os thanks to its Cage clamp system®
Communication with PC, PLCs thanks to the various communication protocols.
Colour codes according to type of signal.
Do not forget to order the end module (508-3959)

750-612 Data Sheet

750-612 Manual
